UL20251 Telephone Cord 电话线

■ 产品说明：
●导体使用单条或绞线，裸软铜或镀锡软铜绞线，或铜箔丝
●芯线数为2至10芯
●PP绝缘
●芯线于被覆押出时从放
●PVC被覆
●额定温度：60℃; 额定电压：150volts
●可通过UL VW-1 垂直耐燃测试
● 参考标准：UL 758；UL 1581

■ 应用：
●适用于电子设备，电话直线及卷线

■ PRODUCT DESCRIPTION：
● Stranded or solid,tinned or bare copper conductor,or tinsel conductor.
● Two to ten conductors only.
● Color-coded polypropylene (PP) insulation.
● Cores are laid parallel of forming a flat.
● PVC jacket.
● Rated temperature：60℃. Rated voltage:150 volts.
● Passes UL VW-1 vertical flame test.
● Reference standard：UL subject 758，UL 1581.

■ APPLICATIONS：
● Internal cable of electronic equipment or as handset wire or telephone cord for subscriber sets.
