■ 说明：
●导体使用单条或绞线，30-16AWG，裸软铜或镀锡软铜线
●PVC绝缘
●额定温度： 80℃； 额定电压：300Volts
●可通过UL-VW-1垂直耐燃测试
●使用标准厚度，易剥，截断容易
●参考标准：UL subject 758；UL 1581

■ 应用：
●一般电子，电器设备内部配线，如机械动作令其磨损，需作适当保护。


■ PRODUCT DESCRIPTION
●Tinned or bare , stranded or solid copper conductor,30-16AWG
●Color-coded PVC insulation
●Rated temperature:80 ℃ . Rated voltage:300 volts.
●Passes UL VW-1 vertical flame test.
●Uniform thickness of wire to ensure easy stripping and cutting .
●Reference standard ： UL subject 758, UL1581

■ APPLICATIONS ：
●For general purpose internal wiring ofelectronic and electrical，protection is required where mechanical demage
